Project Description

PRODUCTS LIST

HDF-TH10 rice grain packing machine Automatic weighing machine

Product Details:

Place of Origin: Zhengzhou,Henan,China
Brand Name: HUAFOOD
Certification: ISO,CE,SGS
Model Number: HDF-TH10

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Packing Speed 25-65 bags/min
Packaging range 10-200g
Granularity 0.05-25mm
Single grain weight 0.02-1g
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Chat Now!
Inquiry

Video

Parameters

Bag style Weighing packaging machine
Packing speed 25-65bag/min
Packaging range 10-200g/bag
Single grain weight 0.02-1g
Precision ±0.5
Power consumption 220v/50Hz/2.8kw
Material Stainless steel
Weight 200kg
Dimensions 750*1280*1950mm
Note Cooperating with sealing machine,Can match pneumatic(air or nitrogen)

Working principle

The grain packaging machine consists of a vibration mechanism, a door opening mechanism and a weighing control system. It uses electromagnetic vibration and high-precision weighing control technology to achieve extremely high repeatability. It uses two-stage vibration and door opening, not only The material time is short, and the measurement accuracy is high, and the shape of the material is not damaged.
The host computer adopts microcomputer and light control switch control, and has functions of automatic metering filling, weighing feedback, automatic correction error, out-of-tolerance alarm, counting, keyboard setting and correction. The hopper is made of anti-corrosion stainless steel and does not contain contaminants. With high sensitivity, high precision and high reliability, it can meet the packaging needs of different specifications.
The weighing packing machine is suitable for quantitative filling of uniform granular materials, such as salt, seeds, food, chemical, washing and other industries.

Feature

1. The electronic scale is directly measured, and the loading is more accurate;
2. Double vibration feeding, higher efficiency;
3. Artificial suit, spot sensing;
4. Weighing: Electronic scale measurement;
5. Fast speed: double vibrating feed or multi-vibration feed;
6. Low noise: no mechanical transmission;
7. Strong corrosion resistance: stainless steel material;
8. Induction bag: The photoelectric port sensor is installed at the bag mouth, and the battery is not connected;
9. Less power consumption: The power of the whole machine does not exceed 250~650W.

rice packing machineweighing packing machine
