Snack packaging pasteurizing machine
| Place of Origin: | Henan Huafood,China |
|---|---|
| Brand Name: | FUAFOOD |
| Certification: | ISO,CE,SGS |
| Model Number: | HDF-P02 |
| Application | kimchi, milk, canned food, condiment, meat and poultry food |
Parameters
|
Pasteurization time( min) |
10-40 |
|
Temperature |
65-98℃, adjustable |
|
Conveyor belt width (mm) |
1000/1200/1500 |
|
Transmission speed |
frequency control |
|
Voltage |
380v/50HZ (or customized) |
|
Power |
conveyor belt: 3kwwater pump: 4kw, air pump: 2.2KW |
|
Steam pressure |
0.3MPa |
|
Capacity(kg/h) |
1000-3000 |
|
Size(mm) |
5000*1500*1650, 8000*1500*1650, |
Video
Working principle
The Snack packaging pasteurizing machine packaged mustard, kimchi, milk, canned food, condiment, meat and poultry food can be continuously sterilized at high temperature (boiling water), then automatically enter the cooling section for rapid cooling, and then enter the air dryer for air drying. Quick packing.
Feates
1. This Snack packaging pasteurizing machine used 304 stainless steel.
2. Use hot water circulation to ensure uniform temperature of the bleach tank to maintain the original color and product rate.
3. Equipped with multi-point measurement function to meet different needs of customers for product temperature.
4. This Snack packaging pasteurizing machine is equipped with an automatic heating system. Temperature can be controlled by itself, speed is controlled by frequency.
5. Each part is equipped with a surf configuration to ensure even blanching and cooling
6. The machine is easy to operate, clean and maintenance, low noise.
